AVAILABLE CLASS / SIZE

TYPE	ANSI CLASS							ACTUATOR
	150LB	300LB	600LB	900LB	1500LB	2500LB	4500LB	P	E	H
FLOATING	½” ~ 8”	½” ~ 8”	-	-	-	-	-	○	○	○
TRUNNION	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	-	○	○	○
TOP ENTRY	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	-	○	○	○

TYPE	FLOATING	TRUNNION	FORGED
DESIGN	ASME B16.34	ASME B16.34	ASME B16.34
	API6D, API608	API6D, API608	API6D, API608
	BS5351	BS5351	BS5351
RATING	#150 up to #300	#150 up to #2500	#150 up to #2500
SIZE	½” up to 8”	2” up to 48”	½” up to 48”
TEMPERATURE(℃)	-29 up to 270 (Soft seat)	-29 up to 270 (Soft seat)	-29 up to 270 (Soft seat)
	-29 up to 500 (Metal Seat)	-29 up to 500 (Metal Seat)	-29 up to 500 (Metal Seat)
	Down to -196 (Cryogenic)	Down to -196 (Cryogenic)	Down to -196 (Cryogenic)
END CONNECTION	Flanged, BW	Flanged, BW	SW, Flanged, BW
BONNET	SIDE ENTRY, TOP ENTRY	SIDE ENTRY, TOP ENTRY	SIDE ENTRY, TOP ENTRY
FACE TO FACE	ASME B16.10	ASME B16.10	TOP ENTRY
LEAKAGE CLASS	MSS SP 61	MSS SP 61	MSS SP 61
	API598	API598	API598
BODY MATERIAL	Carbon Steel	Carbon Steel	Carbon Steel
	Stainless Steel	Stainless Steel	Stainless Steel
	Alloy 20, Duplex	Alloy 20, Duplex	Alloy 20, Duplex
	Nickel-Aluminum Bronze	Nickel-Aluminum Bronze	Nickel-Aluminum Bronze
SEAT MATERIAL	PTFE, RTFE, PEEK, METAL	PTFE, RTFE, PEEK, METAL	PTFE, RTFE, PEEK, METAL
BORE	FULL, REDUCED	FULL, REDUCED	FULL, REDUCED
FEATURES	FIRE SAFETY	FIRE SAFETY	FIRE SAFETY
	FUGITIVE EMISSION	FUGITIVE EMISSION	FUGITIVE EMISSION
	TIGHT SHUT OFF	TIGHT SHUT OFF	TIGHT SHUT OFF
	SPECIAL CLEANING SERVICE	SPECIAL CLEANING SERVICE	SPECIAL CLEANING SERVICE
	CRYOGENIC SERVICE	CRYOGENIC SERVICE	CRYOGENIC SERVICE
	-PORT APPLICABLE	V-PORT APPLICABLE	V-PORT APPLICABLE
	TOXIC SERVICE	TOXIC SERVICE	TOXIC SERVICE
